Tablet

Ideal for areas that are challenging to apply or print on, or for situations where certain processes are omitted

This molded product is made by sintering powder glass. It allows users to choose from a wide range of glass options that best suit their needs. Since the glass is a sintered body that has already undergone debinding, it is easy to handle and eliminates the need for previous processes like coating. It can also be used for areas that are challenging to apply or print on, such as narrow holes or thicker coating areas.

Features
Glass Selection Examples
Dimension Examples
Event Information

Features

You can choose the glass that best suits your needs from a wide variety of options.
The sintered body, having completed the debinding process, is easy to handle and eliminates the need for coating and other pre-processes.
It is also suitable for challenging areas, such as narrow holes or thick paint sections, where application or printing is difficult.

We will offer recommendations on glass selection, shape, dimensions, and more, customized for your specific application.

Glass Selection Examples

Sealing items	Sealing temperature
Sealing items	500 or lower	500-600	700-1000
Kovar Aluminum nitride	LS-1301	BF-0901	BH-7
Alumina	LS-2010	BF-0606	GA-1
Soda plate glass	LS-0118	GA-8	ー
Forsterite	ー	GA-9	GA-11
Iron, nickel	BG-0600	BG-0800	ST-4
