Micro Lens
Micro optical components
Micro Lens is an aspherical lens made from our proprietary high-refractive-index optical glass and advanced micro-mold pressing technology. We offer proposals starting from the optical design stage, supporting the miniaturization and high-density integration of optical modules.
Features
-
High dimensional accuracy is achieved through mold pressing technology.
-
The high refractive index and aspheric surface ensure high coupling efficiency.
-
Excellent heat resistance and compatibility with the reflow process.
-
AR coating, ND coating, and optical filters can be applied to the surface.
-
Available in single-lens and multi-channel arrays.
Specification Examples
| Material | XC-1 (our original optical glass) |
|---|---|
| Refractive index (nd) | 1.81 |
| Shape | Plano-convex array type |
| Radius of curvature | RO. 165mm |
| Thickness | ≤0.450 mm approx. |
| Lens convexity | ≤0.040 mm approx. |
| Pitch | 0.25 mm, 0.50 mm, etc. |
We will create the optimal design based on your specific needs.
